STMicroelectronicsL6206N
L6206NIntegrated Circuits (ICs),PMIC - Full, Half-Bridge DriversSTMICROELECTRONICS - L6206N - IC
Aisa Part#: A20-L6206N
Manufacturer Part #: L6206N
Product Category: Integrated Circuits (ICs),PMIC - Full, Half-Bridge Drivers
Manufacturer: STMicroelectronics
Package Type: 24-PowerDIP (0.300, 7.62mm)
DataSheet:
DataSheet
DataSheetSpecifications
- Mount:Through Hole
- Mounting Type:Through Hole
- Package / Case:24-PowerDIP (0.300, 7.62mm)
- Number of Pins:24
- Operating Temperature:-25°C~125°C TJ
- Packaging:Tube
- JESD-609 Code:e3
- Part Status:Obsolete
- Moisture Sensitivity Level (MSL):1 (Unlimited)
- Number of Terminations:24
- ECCN Code:EAR99
- Resistance:300mOhm
- Terminal Finish:Matte Tin (Sn) - annealed
- Applications:DC Motors, Stepper Motors, Voltage Regulators
- Voltage - Supply:8V~52V
- Terminal Position:DUAL
- Number of Functions:1
- Supply Voltage:48V
- Base Part Number:L6206
- Pin Count:24
- Number of Outputs:4
- Output Voltage:52V
- Max Output Current:5.6A
- Operating Supply Voltage:48V
- Supply Voltage-Min (Vsup):8V
- Number of Channels:2
- Interface:Logic
- Analog IC - Other Type:STEPPER MOTOR CONTROLLER
- Nominal Supply Current:10mA
- Output Configuration:Half Bridge (4)
- Output Current:2.8A
- Output Current per Channel:2.8A
- Rise Time:250ns
- Collector Emitter Voltage (VCEO):52V
- Max Collector Current:2.8A
- Release Time:550 ns
- Voltage - Load:8V~52V
- Fault Protection:Current Limiting, Over Temperature, UVLO
- Rds On (Typ):300m Ω
- Motor Type:Brushed
- Load Type:Inductive
- Features:Bootstrap Circuit
- Height:3.3mm
- Length:31.75mm
- Width:6.6mm
- REACH SVHC:No SVHC
- Radiation Hardening:No
- RoHS Status:ROHS3 Compliant
- Lead Free:Lead Free
