Microchip TechnologyLAN8720A-CP-TR
LAN8720A-CP-TRIntegrated Circuits (ICs),Interface - Drivers, Receivers, TransceiversIC TXRX ETHERNET 24QFN
Aisa Part#: A20-LAN8720A-CP-TR
Manufacturer Part #: LAN8720A-CP-TR
Product Category: Integrated Circuits (ICs),Interface - Drivers, Receivers, Transceivers
Manufacturer: Microchip Technology
Package Type: 24-VFQFN Exposed Pad
DataSheet:
DataSheet
DataSheetSpecifications
- Factory Lead Time:4 Weeks
- Mount:Surface Mount
- Mounting Type:Surface Mount
- Package / Case:24-VFQFN Exposed Pad
- Number of Pins:24
- Operating Temperature:0°C~85°C
- Packaging:Tape & Reel (TR)
- Published:2010
- JESD-609 Code:e3
- Part Status:Active
- Moisture Sensitivity Level (MSL):3 (168 Hours)
- Number of Terminations:24
- Type:Transceiver
- Terminal Finish:Matte Tin (Sn) - annealed
- Voltage - Supply:1.6V~3.6V
- Terminal Position:QUAD
- Number of Functions:1
- Supply Voltage:3.3V
- Terminal Pitch:0.5mm
- Base Part Number:LAN8720A
- Pin Count:24
- Interface:Ethernet
- Max Supply Current:49mA
- Data Rate:100 Mbps
- Protocol:RMII
- Number of Drivers/Receivers:2/2
- Duplex:Full
- Number of Transceivers:1
- Simplex/Duplex:Full Duplex
- Ambient Temperature Range High:85°C
- Height:1mm
- Length:4mm
- Width:4mm
- Radiation Hardening:No
- RoHS Status:ROHS3 Compliant
- Lead Free:Lead Free
Functional compatible component
Form,Package,Functional compatible component
Customers Also Bought 15 Items
Related Models 10 Items
In Stock :28097 PCS
