Analog DevicesLTC6993CS6-3#TRPBF
LTC6993CS6-3#TRPBFIntegrated Circuits (ICs),Logic - MultivibratorsMonostable Multivibrator One Shot with Falling Edge Trigger
Aisa Part#: A20-LTC6993CS6-3#TRPBF
Manufacturer Part #: LTC6993CS6-3#TRPBF
Product Category: Integrated Circuits (ICs),Logic - Multivibrators
Manufacturer: Analog Devices
Package Type: SOT-23-6
DataSheet:
DataSheet
DataSheetSpecifications
- Package / Case:SOT-23-6
- Mounting Type:Surface Mount
- Surface Mount:YES
- Supplier Device Package:TSOT-23-6
- Number of Terminals:6
- Factory Pack QuantityFactory Pack Quantity:150
- Manufacturer:Amphenol
- Brand:Amphenol FCI
- Tradename:Minitek
- Mounting Styles:SMD/SMT
- RoHS:Details
- Package:Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
- Base Product Number:LTC6993
- Mfr:Analog Devices Inc.
- Product Status:Active
- Package Description:VSSOP,
- Package Style:SMALL OUTLINE
- Moisture Sensitivity Levels:1
- Package Body Material:PLASTIC/EPOXY
- Manufacturer Package Code:05-08-1636
- Reflow Temperature-Max (s):NOT SPECIFIED
- Operating Temperature-Max:70 °C
- Rohs Code:Yes
- Manufacturer Part Number:LTC6993CS6-3#TRPBF
- Supply Voltage-Nom (Vsup):3.3 V
- Package Code:VSSOP
- Package Shape:RECTANGULAR
- Part Life Cycle Code:Active
- Ihs Manufacturer:ANALOG DEVICES INC
- Risk Rank:5.36
- Packaging:Tray
- Series:LTC6993-1
- Operating Temperature:0°C ~ 70°C
- JESD-609 Code:e3
- Pbfree Code:No
- Terminal Finish:Matte Tin (Sn)
- Subcategory:Power Connectors
- Technology:CMOS
- Voltage - Supply:2.25 V ~ 5.5 V
- Terminal Position:DUAL
- Terminal Form:GULL WING
- Peak Reflow Temperature (Cel):NOT SPECIFIED
- Number of Functions:1
- Terminal Pitch:0.95 mm
- Reach Compliance Code:compliant
- Pin Count:6
- JESD-30 Code:R-PDSO-G6
- Qualification Status:Not Qualified
- Brand Name:Analog Devices Inc
- Supply Voltage-Max (Vsup):5.5 V
- Temperature Grade:COMMERCIAL
- Supply Voltage-Min (Vsup):2.25 V
- Propagation Delay:11 ns
- Family:6993
- Current - Output High, Low:16mA, 16mA
- Seated Height-Max:1 mm
- Logic Type:Monostable
- Product Type:Power to the Board
- Output Polarity:TRUE
- Logic IC Type:MONOSTABLE MULTIVIBRATOR
- Independent Circuits:1
- Schmitt Trigger Input:No
- Number of Data/Clock Inputs:1
- Product Category:Power to the Board
- Width:1.625 mm
- Length:2.9 mm
