NC7SZ00P5 Integrated Circuits (ICs),Logic - Gates and InvertersNAND Gate IC 1 Channel SC-70-5DataSheet
Details Information
Aisa Part#: A19-NC7SZ00P5
Manufacturer Part #: NC7SZ00P5
Product Category: Integrated Circuits (ICs),Logic - Gates and Inverters
Manufacturer: ON Semiconductor
Package Type: 5-TSSOP, SC-70-5, SOT-353
CAD Model:
By downloading CAD models from Asia, you agree to our Terms & Conditions and Privacy Policy.
Specifications
  • Mfr: ON Semiconductor
  • Series: 7SZ
  • Package: Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
  • Package: Bulk
  • Part Status: Obsolete
  • Part Status: Discontinued at Digi-Key
  • Mounting Type: Surface Mount
  • Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Base Product Number: NC7SZ0
  • Package / Case: 5-TSSOP SC-70-5 SOT-353
  • Voltage - Supply: 1.65V ~ 5.5V
  • Supplier Device Package: SC-70-5
  • Logic Type: NAND Gate
  • Number of Inputs: 2
  • Current - Output High Low: 32mA 32mA
  • Number of Circuits: 1
  • Max Propagation Delay @ V Max CL: 4.3ns @ 5V 50pF
  • Logic Level - Low: -
  • Logic Level - High: -
  • Current - Quiescent (Max): 2µA
