NC7SVL04P5X Integrated Circuits (ICs),Logic - Gates and InvertersInverter IC 1 Channel SC-70-5
DataSheet
Quantity:
Details Information
Aisa Part#: A19-NC7SVL04P5X
Manufacturer Part #: NC7SVL04P5X
Product Category: Integrated Circuits (ICs),Logic - Gates and Inverters
Manufacturer: ON Semiconductor
Package Type: 5-TSSOP, SC-70-5, SOT-353
CAD Model:
AltiumEagleOrCadPADSKiCad
By downloading CAD models from Asia, you agree to our Terms & Conditions and Privacy Policy.
Specifications
  • Mfr: ON Semiconductor
  • Series: 7SVL
  • Package: Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Base Product Number: NC7SVL
  • Package / Case: 5-TSSOP SC-70-5 SOT-353
  • Voltage - Supply: 0．9V ~ 3．6V
  • Supplier Device Package: SC-70-5
  • Logic Type: Inverter
  • Number of Inputs: 1
  • Current - Output High Low: 24mA 24mA
  • Number of Circuits: 1
  • Max Propagation Delay @ V Max CL: 3．5ns @ 3V 30pF
  • Logic Level - Low: 0．7V ~ 0．8V
  • Logic Level - High: 0．9V ~ 1．5V
  • Current - Quiescent (Max): 900nA
Functional compatible component(2) Form,Package,Functional compatible component(1)
Mfr. Part # Mfr. Description Compare
NC7SVL32P5X
Logic		 ON Semiconductor Tiny Logic Low-ICCT Two-Input OR Gate， 3000-REEL NC7SVL04P5X vs NC7SVL32P5X
NC7SVL04P5X
Logic		 Fairchild Semicond TinyLogic Low-ICCT Inverter， 5LD， SC70， EIAJ SC-88A， 1.25MM WIDE， 3000/TAPE REEL NC7SVL04P5X vs NC7SVL04P5X
Parts With Similar Specs The following parts have similar specifications to integrated device technology
This Part
Authorized Distributors:8
Case/Package:SC
Common Mode Rejection Ratio:-
Gain Bandwidth Product:-
Input Offset Voltage (Vos):-
Max Supply Voltage:3.6 V
Min Supply Voltage:900 mV
Number of Circuits:1
Number of Pins:5
Operating Supply Current:-
Price @ 1,000:USD 0.050
Slew Rate:-

Similar
