NC7SP08P5X Integrated Circuits (ICs),Logic - Gates and InvertersAND Gate IC 1 Channel SC-70-5DataSheet
Details Information
Aisa Part#: A19-NC7SP08P5X
Manufacturer Part #: NC7SP08P5X
Product Category: Integrated Circuits (ICs),Logic - Gates and Inverters
Manufacturer: ON Semiconductor
Package Type: 5-TSSOP, SC-70-5, SOT-353
CAD Model:
By downloading CAD models from Asia, you agree to our Terms & Conditions and Privacy Policy.
Specifications
  • Mfr: ON Semiconductor
  • Series: 7SP
  • Package: Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Base Product Number: NC7SP0
  • Package / Case: 5-TSSOP SC-70-5 SOT-353
  • Voltage - Supply: 0.9V ~ 3.6V
  • Supplier Device Package: SC-70-5
  • Logic Type: AND Gate
  • Number of Inputs: 2
  • Current - Output High Low: 2.6mA 2.6mA
  • Number of Circuits: 1
  • Max Propagation Delay @ V Max CL: 9.2ns @ 3.3V 30pF
  • Logic Level - Low: 0.7V ~ 0.9V
  • Logic Level - High: 1.6V ~ 2.1V
  • Current - Quiescent (Max): 900nA
Functional compatible component(5) Form,Package,Functional compatible component(8)
Mfr. Part # Mfr. Description Compare
NL17SG08DFT2G
Logic
ON Semiconductor Single 2-Input AND Gate, 3000-REEL NC7SP08P5X vs NL17SG08DFT2G
NC7SP08P5X_NL
Logic
Fairchild Semicond AND Gate, P Series, 1-Func, 2-Input, CMOS, PDSO5, 1.25 MM, EIAJ, SC-88A, SC-70, 5 PIN NC7SP08P5X vs NC7SP08P5X_NL
74AUP1G08GW
Logic
NXP Semiconductors IC AUP/ULP/V SERIES, 2-INPUT AND GATE, PDSO5, 1.25 MM, PLASTIC, MO-203, SC-88A, SOT353-1, TSSOP-5, G NC7SP08P5X vs 74AUP1G08GW
NC7SP08P5X
Logic
Fairchild Semicond AND Gate, P Series, 1-Func, 2-Input, CMOS, PDSO5, 1.25 MM, SC-88A, SC-70, 5 PIN NC7SP08P5X vs NC7SP08P5X
74AUP1G08GW-Q100
Logic
Nexperia AND Gate, AUP/ULP/V Series, 1-Func, 2-Input, CMOS, PDSO5 NC7SP08P5X vs 74AUP1G08GW-Q100
Parts With Similar Specs The following parts have similar specifications to integrated device technology
This Part
NC7SP08P5X
Authorized Distributors:11
Case/Package:SC
High Level Output Current:-2.6 mA
Logic Function:AND
Low Level Output Current:2.6 mA
Max Supply Voltage:3.6 V
Min Supply Voltage:900 mV
Number of Circuits:1
Number of Inputs:2
Number of Pins:5
Price @ 1,000:USD 0.099
Propagation Delay:12.2 ns
Quiescent Current:900 nA
