NC7S86M5X Integrated Circuits (ICs),Logic - Gates and InvertersXOR (Exclusive OR) IC 1 Channel SOT-23-5DataSheet
Details Information
Aisa Part#: A19-NC7S86M5X
Manufacturer Part #: NC7S86M5X
Product Category: Integrated Circuits (ICs),Logic - Gates and Inverters
Manufacturer: ON Semiconductor
Package Type: SC-74A, SOT-753
CAD Model:
By downloading CAD models from Asia, you agree to our Terms & Conditions and Privacy Policy.
Specifications
  • Mfr: ON Semiconductor
  • Series: 7S
  • Package: Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Base Product Number: NC7S86
  • Package / Case: SC-74A SOT-753
  • Voltage - Supply: 2V ~ 6V
  • Supplier Device Package: SOT-23-5
  • Logic Type: XOR (Exclusive OR)
  • Number of Inputs: 2
  • Current - Output High Low: 2.6mA 2.6mA
  • Number of Circuits: 1
  • Max Propagation Delay @ V Max CL: 17ns @ 6V 50pF
  • Logic Level - Low: 0.5V
  • Logic Level - High: 1.5V
  • Current - Quiescent (Max): 1µA
