NC7S14P5X Integrated Circuits (ICs),Logic - Gates and InvertersInverter IC 1 Channel Schmitt Trigger SC-70-5
DataSheet
Quantity:
Details Information
Aisa Part#: A19-NC7S14P5X
Manufacturer Part #: NC7S14P5X
Product Category: Integrated Circuits (ICs),Logic - Gates and Inverters
Manufacturer: ON Semiconductor
Package Type: 5-TSSOP, SC-70-5, SOT-353
CAD Model:
AltiumEagleOrCadPADSKiCad
By downloading CAD models from Asia, you agree to our Terms & Conditions and Privacy Policy.
Specifications
  • Mfr: ON Semiconductor
  • Series: 7S
  • Package: Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Features: Schmitt Trigger
  • Operating Temperature: -40°C ~ 85°C
  • Base Product Number: NC7S14
  • Package / Case: 5-TSSOP SC-70-5 SOT-353
  • Voltage - Supply: 2V ~ 6V
  • Supplier Device Package: SC-70-5
  • Logic Type: Inverter
  • Number of Inputs: 1
  • Current - Output High Low: 2．6mA 2．6mA
  • Number of Circuits: 1
  • Max Propagation Delay @ V Max CL: 17ns @ 6V 50pF
  • Logic Level - Low: 0．3V ~ 1．5V
  • Logic Level - High: 1．5V ~ 4．2V
  • Current - Quiescent (Max): 1µA
Functional compatible component(10) Form,Package,Functional compatible component(10)
Mfr. Part # Mfr. Description Compare
MC74HC1G14DFT2G
Logic		 Rochester Electron HC/UH SERIES， 1-INPUT INVERT GATE， PDSO5， LEAD FREE， SC-70， SC-88A， SOT-353， 5 PIN NC7S14P5X vs MC74HC1G14DFT2G
74HC1G14GW，165
Logic		 Nexperia 74HC(T)1G14 - Inverting Schmitt trigger TSSOP 5-Pin NC7S14P5X vs 74HC1G14GW，165
TC7S14FU(TE12L)
Logic		 Toshiba America El IC HC/UH SERIES， 1-INPUT INVERT GATE， PDSO5， PLASTIC， SSOP-5， Gate NC7S14P5X vs TC7S14FU(TE12L)
HD74HC1G14-EL
Logic		 Renesas Electronic HC/UH SERIES， 1-INPUT INVERT GATE， PDSO5， CMPAK-5 NC7S14P5X vs HD74HC1G14-EL
MC74HC1G14DFT2
Logic		 ON Semiconductor HC/UH SERIES， 1-INPUT INVERT GATE， PDSO5， SC-70， SC-88A， SOT-353， 5 PIN NC7S14P5X vs MC74HC1G14DFT2
HD74HC1G14CME-E
Logic		 Renesas Electronic HC/UH SERIES， 1-INPUT INVERT GATE， PDSO5， CMPAK-5 NC7S14P5X vs HD74HC1G14CME-E
74HC1G14GW
Logic		 Nexperia Inverter， HC/UH Series， 1-Func， 1-Input， CMOS， PDSO5 NC7S14P5X vs 74HC1G14GW
NC7S14P5
Logic		 Fairchild Semicond Inverter， HC/UH Series， 1-Func， 1-Input， CMOS， PDSO5， 1.25 MM， EIAJ， SC-88A， SC-70， 5 PIN NC7S14P5X vs NC7S14P5
935245730165
Logic		 NXP Semiconductors IC HC/UH SERIES， 1-INPUT INVERT GATE， PDSO5， PLASTIC， SC-88A， 5 PIN， Gate NC7S14P5X vs 935245730165
74HC1G14GW-Q100H
Logic		 Nexperia 74HC(T)1G14-Q100 - Inverting Schmitt trigger TSSOP 5-Pin NC7S14P5X vs 74HC1G14GW-Q100H
