NC7NP14K8X Integrated Circuits (ICs),Logic - Gates and InvertersInverter IC 3 Channel Schmitt Trigger US8DataSheet
Details Information
Aisa Part#: A19-NC7NP14K8X
Manufacturer Part #: NC7NP14K8X
Product Category: Integrated Circuits (ICs),Logic - Gates and Inverters
Manufacturer: ON Semiconductor
Package Type: 8-VFSOP (0.091"", 2.30mm Width)
CAD Model:
By downloading CAD models from Asia, you agree to our Terms & Conditions and Privacy Policy.
Specifications
  • Mfr: ON Semiconductor
  • Series: 7NP
  • Package: Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Features: Schmitt Trigger
  • Operating Temperature: -40°C ~ 85°C
  • Base Product Number: NC7NP14
  • Package / Case: 8-VFSOP (0.091"" 2.30mm Width)
  • Voltage - Supply: 0.9V ~ 3.6V
  • Supplier Device Package: US8
  • Logic Type: Inverter
  • Number of Inputs: 3
  • Current - Output High Low: 2.6mA 2.6mA
  • Number of Circuits: 3
  • Max Propagation Delay @ V Max CL: 9.2ns @ 3.3V 30pF
  • Logic Level - Low: 0.1V ~ 0.6V
  • Logic Level - High: 0.6V ~ 2.6V
  • Current - Quiescent (Max): 900nA
Functional compatible component(6)
Mfr. Part # Mfr. Description Compare
NC7NP14L8X
Logic
Rochester Electron P SERIES, TRIPLE 1-INPUT INVERT GATE, QCC8, 1.60 MM, LEAD FREE, MO-255UAAD, MICROPAK-8 NC7NP14K8X vs NC7NP14L8X
NC7NP04K8X
Logic
ON Semiconductor TinyLogic ULP Triple Inverter, VSOP 8L, 9000-TAPE REEL NC7NP14K8X vs NC7NP04K8X
74AUP3G04DC,125
Logic
Nexperia 74AUP3G04 - Low-power triple inverter SSOP 8-Pin NC7NP14K8X vs 74AUP3G04DC,125
NC7NP04L8X
Logic
Fairchild Semicond Inverter, P Series, 3-Func, 1-Input, CMOS, 1.60 MM, LEAD FREE, MICROPAK-8 NC7NP14K8X vs NC7NP04L8X
74AUP3G04GM,125
Logic
NXP Semiconductors 74AUP3G04 - Low-power triple inverter QFN 8-Pin NC7NP14K8X vs 74AUP3G04GM,125
74AUP3G04GT,115
Logic
NXP Semiconductors 74AUP3G04 - Low-power triple inverter SON 8-Pin NC7NP14K8X vs 74AUP3G04GT,115
